500-Sheet Finisher (D372)
SM 1-53 D017/D018/D019/D020
Installation
1.14 500-SHEET FINISHER (D372)
1.14.1 ACCESSORY CHECK
Check the quantity and condition of the accessories against the following list.
No Description Q’ty For D017/D018/D019/D020
1 Unit Holder 1 Yes
2 Shift Tray 1 Yes
3 Holder Bracket 1 Yes
4 Screw: M3 x 8 4 Yes (Use 2)
5 Screw: M3 x 6 1 Yes
6 Screw: M4 x 14 4 Yes (Use 3)
7 Screw: M4 x 20 4 No
8 Support Bracket 2 No
9 Support Bracket Cover 2 No
1.14.2 INSTALLATION PROCEDURE
 Unplug the main machine power cord before starting the following procedure.
