PM Table
SM 2-1 D017/D018/D019/D020
Preventive
Maintenance
2. PREVENTIVE MAINTENANCE
2.1 PM TABLE
 The amounts mentioned as the PM interval indicate the number of prints.
 After carrying out PM, clear the maintenance counter (SP7-804).
Symbol key: C: Clean, R: Replace, L: Lubricate, I: Inspect
EM 120K 240K 360K NOTE
SCANNER/LASER OPTICS
Reflector C C C Optics cloth
1st Mirror C C C C Optics cloth
2nd Mirror C C C C Optics cloth
3rd Mirror C C C C Optics cloth
Scanner Guide Rails C C C Do not use alcohol.
Platen Sheet Cover C I I I
Replace the platen sheet, if
necessary.
Dry cloth or alcohol
Exposure Glass C C C Dry cloth or alcohol
Toner Shield Glass C C C Optics cloth
APS Sensor C C C Dry cloth or blower brush
EM 120K 240K 360K NOTE
AROUND THE DRUM
Transfer/Separation R R R
