Overview
D017/D018/D019/D020 6-2 SM
1. 2nd scanner
2. Original width sensor
3. Exposure lamp
4. 1st scanner
5. Original length sensor
6. Lens
7. Scanner motor
8. SBU board
9. Exit roller
10. Fusing hot roller
11. Fusing pressure roller
12. Cleaning unit
13. OPC drum
14. Transfer roller
15. Development roller
16. ID sensor
17. Registration roller
18. Friction pad
19. Paper feed roller
20. Bottom plate
21. Tray heater
22. Polygon mirror motor
23. Laser unit
24. Toner supply bottle holder
25. Drum charge roller
26. Scanner home position sensor
