10. Remove all the orange tape from the drum unit. Do not remove the tape coming out of the

unit.

11. Remove the cap.

BMV192S

12. Holding the green grip on the left and the handle on the front, carefully insert the front end

into the space horizontally.

BMV071S

Insert it horizontally as shown below.

BMV073S

Replacing the Black Drum Unit/Color Drum Units

147
