Ricoh Aficio SP C820DN

5. Tighten the two screws to secure the interface board.
BMV169S
6. Remove protective paper from the hook-and-loop fasteners, and then place them as far
away from each other as possible on the upper side of the printer rear.
BMV170S
Make sure that the hook-and-loop fasteners are not placed over any screw holes or seams on the
printer body.
7. Remove protective paper from antennas, and then attach the antennas upright to the hook-
and-loop fasteners. Attach the antenna coming from a black ferrite core on the right side of
the printer rear.
BMV171S
: Attach the antennas so that they protrude above the top of the printer.
2. Installing Options
60
2
