Connecting the Printer
118
USB Connection
❒ USB2.0 interface cable is not supplied. Obtain it separately, according to the
computer you are using.
❒ USB connection is possible under Windows 98 SE/Me/2000/XP, Windows
Server 2003, Mac OS X v10.3.3 or higher.
❒ Windows 98SE/Me supports USB1.1 speeds.
❒ USB connection with Macintosh is only possible via the printer's USB port.
A Connect the square-shaped connector of the USB2.0 cable to the USB
port.
B If the gigabit ethernet board is attached, connect the square-shaped
connector of the USB2.0 cable to the USB port of the board.
❒ The printer's ethernet and USB ports are not available when the gigabit
ethernet board is attached to the printer.
For details about attaching the gigabit ethernet board, see p.84 “Attaching
Gigabit Ethernet Type 7300”.
To Next Page
