Installing Options
97
Attaching IEEE 1284 Interface Board Type
A
❒ Before handling the IEEE 1284 interface board, ground yourself by touching
something metal to discharge any static electricity. Static electricity can dam-
age the IEEE 1284 interface board.
❒ Do not subject the IEEE 1284 interface board to physical shocks.
A Check the contents of the box.
❖ IEEE 1284 Interface Board Type A
B Turn off the power then unplug the power cable, and then interface ca-
ble.
C Slowly open the front cover of the printer, remove the green screwdriv-
er, and then close the cover.
p.54 “Using the Screwdriver”
D Remove the screws by turning them counterclockwise using the provid-
ed screwdriver, and then remove the cover of the IEEE 1284 interface
board slot.
The removed screws and cover will not be needed now but save them in case
the cover needs to be reattached.
To Next Page
