1.Replacement and Adjustment
28
following is the procedure for replacing the paper feed sensor of tray 1.
1. Pull out the paper tray.
2. Remove the top cover [A] of the transport roller unit ( x2).
3. Remove the paper feed sensor bracket [A] ( x2)
4. Remove the paper feed sensor [A] ( x1, x1)
To Next Page
