Ricoh D3EW User Manual

1.Replacement and Adjustment
87
LCIT Exit Sensor
1. Remove the bracket [A] ( x1, x1)
2. Remove the LCIT exit sensor [A] ( x1)
LCIT Exit Roller Contact Sensor
1. Remove the stay [A] from the vertical feed unit ( x2).
2. Remove the bracket [A] ( x1, x1)
 The top stay is in the way. Use a small screwdriver to remove it.
