1.Replacement and Adjustment
88
3. Remove the LCIT exit roller contact sensor [A] ( x1, x1)
Vertical Transport Unit Cooling Fan
1. Remove the rear right and rear left covers (Rear Right Cover, Rear Left Cover).
2. Remove the vertical transport unit cooling fan [A] with the bracket ( x2, x1, x1).
To Next Page
