9. Holding the green handle, remove the protective materials from both ends, and then take
the development unit out of the plastic bag.
BEK037S
After taking the new development unit from the box, do not to shake or jar the unit.
10. Remove the desiccant from the development unit.
11. Remove the tapes from both sides, and then take out the fixtures by pulling the wire with a
red tag toward you.
BEK060S
12. Remove the tape from the side of the development unit ( ), and then take out the
transparent tape ( ).
BEK061S
While pulling out the tape, keep the development unit horizontal. Tilting or shaking the unit might
cause the toner to scatter.
6. Replacing Consumables
118
6
