10. On the rear of the unit, attach two brackets using the remaining screws.
Tighten the screws firmly using a coin.
11. Plug in the power cord, and then turn on the printer.
12. Print the configuration page to confirm that the unit was attached correctly.
• To confirm whether the optional paper feed unit was correctly attached, print the configuration page,
and check "Attached Equipment" on the configuration page. If the unit was attached correctly, the
following will be displayed:
• 1000-sheet paper feed unit: Lower Paper Trays
• 2000-sheet paper feed unit: Tray 3
• If the optional paper feed unit was not installed properly, repeat the procedure from step 2. If it cannot
be installed correctly even after reattempting installation, contact your sales or service representative.
• If the print area is not centered correctly, see "Adjusting Printing Position".
• For information about printing the configuration page, see "Test Printing", Quick Installation Guide.
• p.147 "Adjusting Printing Position"
Attaching the Paper Feed Unit
29
