3. Unplug cables from the USB and Ethernet ports, and then cover them with the protective
caps.
BEK142S
4. Loosen the two screws and remove the slot cover.
BEK165S
The removed cover will not be reused.
5. Fully insert the Gigabit Ethernet board.
BEK143S
Confirm that the Gigabit Ethernet board is firmly connected to the controller board.
2. Installing Options
38
2
