Ricoh MLP150DN Operaing Instructions

2. Connect the Ethernet cable to the Ethernet port that is located on the left side of the printer.
BEK151S
3. Connect the other end of the cable to the network, for example using a hub.
Connecting to the Ethernet port of the Gigabit Ethernet board
1. Attach the two ferrite cores to the Ethernet cable.
Attach the core supplied with the printer at the printer end of the Ethernet cable. Attach the core
supplied with the Gigabit Ethernet board about 10 cm (4 inches) from the connector ( ), making a
loop as shown.
BEK108S
2. Connect the Ethernet cable to the Ethernet port of the Gigabit Ethernet board.
BEK152S
3. Connecting the Printer Cables
50
3
