Fusing
• Allow time for the unit to cool before doing the following procedure.
Fusing Unit
1. Rear cover [A]
2. Fusing unit [B] (hooks [C] x 2).
• Lift both hooks before attempting to remove the fusing unit from the machine.
Hot Roller and Fusing Lamp
1. Fusing Unit (* Fusing Unit)
