Ricon Mirage F9T User Manual

32DF9T02.B
3 - 5
OK Requires
repair
Repair at next
service
Repair before re-
turning to service
Inspect four guide rollers, and lube with
Zep PLS.
Inspect primary and secondary drive
chains. Adjust, if needed. Lube with
Zep PLS lubricating spray.
Check hydraulic cylinder for leaks;
spray trunnion and center pivot pin with
Zep PLS lubricating spray.
Spray eight pins on lifting frame with
Zep PLS lubricating spray.
Remove rollstop covers from both sides
of platform; clean rollstop pivot points
with Zep I.D. Red degreaser. Replace
covers.
Stow platform. Rotate manual platform
release and pull platform out com-
pletely. Platform must lock in place
(cannot be pushed back in). Rotate
manual release and push platform in
completely
. Platform must lock in place
(cannot be pulled out).
NOTES:
Print name:
Signature:
