32DF9T02.C
4 - 16
WARNING!
•• WEAR PROTECTIVE CLOTHING AND EYE PROTECTION AT ALL TIMES. BAT-
TERIES CONTAIN ACID THAT CAN BURN. IF ACID COMES INTO CONTACT
WITH SKIN, IMMEDIATELY FLUSH AFFECTED AREA WITH WATER AND WASH
WITH SOAP.
•• WORK IN A PROPERLY VENTILATED AREA. DO NOT SMOKE OR USE AN OPEN
FLAME IN THE VICINITY OF BATTERY.
•• DO NOT LAY ANYTHING METALLIC ON TOP OF BATTERY.
5) Disconnect positive battery cable at vehicle battery compartment.
6) Loosen motor retaining clamp that fastens gearmotor to gearmotor support.
7) Loosen two nuts fastening gearbox to carriage.
8) Move gearmotor assembly toward driveshaft to slacken chain. A small pry bar may be in-
serted between motor and front of carriage to gain leverage.
NOTE: DO NOT FORCE THE GEARMOTOR. Further loosen two nuts, or loosen motor retaining
clamp to obtain more movement.
9) Remove primary drive chain master link and primary drive chain.
b. DRIVE CHAIN INSTALLATION
Final Drive Chain
1) Refer to Figure 4-17. Verify the two screws fastening the intermediate shaft mounting
bracket to carriage are loose.
2) Install final drive chain around sprocket on final driveshaft, and around sprocket on interme-
diate shaft. Install master link.
3) Refer to Final Drive Chain Adjustment section and adjust final drive chain.
Primary Drive Chain
1) Refer to Figure 4-17. Loosen motor retaining clamp that fastens the gearmotor to gearmo-
tor support.
2) Loosen nuts fastening gearbox to carriage.
3) Install primary drive chain around sprocket on gearbox output shaft, and around clutch
sprocket. Install master link.
4) Refer to Primary Drive Chain Adjustment section and adjust primary drive chain.
