24
ADJUSTING THE RIDING POSITION
Height Adjustment:
• Open the quick release lever C.
• Press the pin D and adjust the stem to
one of five height positions until the pin D
engages.
• Attention: the stem should not be extend
-
ed beyond the “MIN. INSERTION“ mark!
Use the stem only in the five positions in
which the pin engages.
• Align the handlebar in the direction of
travel and close the quick release lever C.
C
D
ADJUSTABLE STEM AT KENDU/ LOAD/PONY
The stem of the Kendu, Load and Pony is
adjustable in both height and angle. Both
adjustments can be made without tools by
means of a locking pin and quick releases.
Angle adjustment:
• Open both quick release levers A on the
front hinge.
• Press the side button B and adjust the stem
in one of the three angle positions. Release
the button again moving the stem until it
clicks into place (possibly move the stem a
little back and forth).
• Attention: Only use the stem in the three
positions in which the pin engages!
• Close both quick release levers A.
• In engaged state both red marks are in one
line.
A
B
ATTENTION!
Before each ride, ensure that the pin
is rmly in place and quick-release
levers are completely closed. If the
bars or stem move while driving by
yourself, have your dealer inspect
it immediately as this could be very
dangerous.
