39
V-brakes synchronization
The V-brakes have to be synchronized by ad
-
justing the spring preload using the respec-
tive adjustment screws A.
• Turn these screws until the pads are the
same distance from the rim.
Adjusting the brake cable
When the brake lever pulls all the way to
the handlebar, the brake cable must be
readjusted.
• Loosen the knurled lock ring B where the
brake cable enters the brake lever.
• Turn slotted barrel adjuster C a few turns.
The free travel of the brake lever is re
-
duced.
• Hold the barrel adjuster C while tightening
the lock ring B firmly against it so that the
barrel adjuster is locked in place.
• Take care that the slot of the adjustment
screw is not orientated to top or front. Oth
-
erwise water and dust could enter.
C
B
A A
TIP!
Be sure to try the brakes in a
trac free area to get a feel for
the newly adjusted brakes.
