Document Overview
This manual gives you a quick overview of the front and rear panel, user interface as
well as basic operation methods of DHO1000 series.
TIP
For the newest version of this manual, download it from RIGOL
Publication Number
QGA32103-1110
Software Version
Software upgrade might change or add product features. Please acquire the latest
version of the manual
Format Conventions in this Manual
1. Key
The front panel key is denoted by the menu key icon. For example,
indicates the "DEFAULT" key.
2. Menu
The menu item is denoted by the format of "Menu Name (Bold) + Character
Shading" in the manual. For example, Setup indicates the "Setup" sub-menu under
the "Utility" function menu. You can click or tap Setup to access the "Setup" menu.
3. Operation Procedures
The next step of the operation is denoted by ">" in the manual. For example,
> Storage indicates first clicking or tapping and then clicking or tapping
Storage.
4. The front/rear panel connector is denoted by "Brackets + Connector Name (Bold)",
for example, [AUX OUT].
Content Conventions in this Manual
DHO1000 series digital oscilloscope includes the following models. Unless otherwise
specified, this manual takes the 4-channel model DHO1104 as an example to illustrate
the basic operation methods of DHO1000 series.
Model Max. Analog Bandwidth Analog Channels
DHO1072 70 MHz 2
Document Overview
6
