TIP
• When you adjust the horizontal time b
ase, the waveform displayed on the screen will also
change, and the total number of lines containing the decoding information in the event
table will also be changed.
• The displayed decoded data information in the bus is related to the value of the
horizontal time base. Reducing the horizontal time base can help you view the detailed
information.
Export
When the oscilloscope is in "STOP" state, you can export the time and its
corresponding decoded data in the event table.
In Decode menu, click or tap
Export, then the save setting int
erface is displayed. You
can export the data to the internal memory or the external USB storage device (only
when detected) in *.csv format. For details, refer to
Store and Load
.
Interpret the Decoded LIN Data
• Break (Sync Break): expressed in Hex, identified as "Break:".
• SYNC (Sync): expressed in Hex, identified as "SYNC:".
• ID (Frame ID): expressed in Hex, identified as "ID:".
• Data (Data): Its display format is the same as that of the bus data (Hex, Dec, Bin,
or ASCII), identified as "Data:".
• Checksum (check sum): expressed in Hex, identified as "Checksum:". When errors
occur, it is displayed as a red patch.
• Wakeup (wake up symbol): identified as "Wakeup:".
Protocol Decoding
Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
DHO1000 User Guide
197
