Rigol DP1308A Service Guide

RIGOL
DP1308A Service Guide
V
DP1308A Overview
DP1308A programmable linear DC power supply is designed with high performance
and 80W triple-output. Configured with clear user interface, excellent specifications
and multiple standard interfaces, DP1308A can fulfill diversified testing demands.
Main Features:
 4.3 inch, 16M true color TFT LCD;
 Individual and controllable triple-channel output with up to 80 W total power;
 Low ripples noise, the output noise and ripples <350μVrms/2mVpp;
 Excellent linear regulation rate: <0.01%+2mV (voltage), <0.01%+250μA
(current);
 Excellent load regulation rate: <0.01%+2mV (voltage), <0.01%+250μA
(current);
 Overvoltage/overcurrent protection function. Implement effective protection for
loads by setting the overvoltage and overcurrent parameters;
 Two-level overtemperature protection;
 Enable to set the parameters of the store and recall system;
 Timing output;
 Waveform display: real-time display of output voltage/current waveform, which,
in combination with the digital display of the voltage, current and power, clearly
shows the output state of the instrument;
 Standard interfaces: USB Device, USB Host, LAN and GPIB;
 Support USB storage device storage;
 Support remote control via Web;
 Support remote control via commands;
 Conform to LXI-C class instrument standard;
 One-key help function;
 Support Chinese & English interface and input method.

Rigol DP1308A Specifications

General

Brand	Rigol
Model	DP1308A
Category	Power Supply
Language	English
