Chapter 5 To Trigger the Oscilloscope RIGOL
DS1000Z Users Guide
5-31
Delay Type:
Press DelayType to set the time limit condition of delay trigger.
>: trigger when the time difference (T) between the specified edges of source
A and source B is greater than the preset time limit. Press Time to set the delay
time in delay trigger and the range is from 8 ns to 10 s.
<: trigger when the time difference (T) between the specified edges of source
A and source B is lower than the preset time limit. Press Time to set the delay
time in delay trigger and the range is from 8 ns to 10 s.
<>: trigger when the time difference (T) between the specified edges of
source A and source B is greater than the lower limit of the preset time and
lower than the upper limit of the preset time. Press Upper Limit to set the
upper limit of the delay time in delay trigger and the range is from 16 ns to 10 s.
Press Lower Limit to set the lower limit of the delay time in delay trigger and
the range is from 8 ns to 9.99 s. Note that the time lower limit must be lower
than the time upper limit.
><: trigger when the time difference (T) between the specified edges of
source A and source B is lower than the lower limit of the preset time or greater
than the upper limit of the preset time. Press Upper Limit to set the upper limit
of the delay time in delay trigger and the range is from 16 ns to 10 s. Press
Lower Limit to set the lower limit of the delay time in delay trigger and the
range is from 8 ns to 9.99 s. Note that the time lower limit must be lower than
the time upper limit.
Trigger Mode:
Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto,
normal or single. The corresponding status light of the current trigger mode turns on.
Trigger Setting:
Press Setting to set the trigger parameters (trigger holdoff and noise rejection)
under this trigger type.
Trigger Level:
Use TRIGGER LEVEL to modify the level. For details, please refer to the
description of
Trigger Levelon page 5-9.
