To Output Noise Waveform
Press Src1 Setup to enter the waveform setting interface. Press Wave to select
“Noise”, at this point, you can output noise signals with specified amplitude.
1. Output
Press Output to turn the signal output on or off.
2. To set amplitude
Press Amplitude to set the amplitude of the current signal and the range
available is from 20 mVpp to 5Vpp (when the impedance is “HighZ”) or from 10
mVpp to 2.5 Vpp (when the impedance is “50 Ω”). For setting method please
refer to the instruction of “
To set amplitude”.
3. To set the DC offset voltage
Press Offset to set the DC offset of the current signal and the range available is
from “-2.5 V + the amplitude value currently set/2” (when the impedance is
“HighZ”) to “2.5 V + the amplitude value currently set/2” (when the impedance is
“50 Ω”). For setting method please refer to the instruction of “
To set the DC
offset voltage”.
Note that the offset value is only remained three significant figures. For example,
when the amplitude is set to 10 mV (the impedance is 50 Ω), the offset range
calculated is -1.245 V to 1.245 V, but the actual offset range is -1.24 V to 1.24 V.
