RIGOL Chapter 12 Signal Source
DS1000Z User’s Guide
12-2
To Output Basic Waveform
To Output Sine Waveform
Press Src1 Setup to enter the waveform setting interface. Press Wave to select
“Sine”, at this point, you can set relative parameters of the sine signal.
1. Output
Press Output to turn the signal output on or off.
2. To set frequency
Press Frequency to set the frequency of the current signal and the range
available is from 100 mHz to 25 MHz. Note that different waveform has different
frequency, the frequency ranges of square and pulse are 100 mHz to 15 MHz; the
frequency range of ramp is 100 mHz to 100 kHz.
Method one:
Rotate
directly to set the desired frequency value.
Method two:
Press
to input desired paramrter values and unist directly using the pop-up
numeric keyboard.
3. To set amplitude
Press Amplitude to set the amplitude of the current signal and the range
available is from 20 mVpp to 5 Vpp (if the impedance is “HighZ”) or from 10
mVpp to 2.5 Vpp (if the impedance is “50 Ω”).
Method one:
Rotate
directly to set the desired implitude value.
Method two:
Press
to input desired paramrter values and unist directly using the pop-up
numeric keyboard.
4. To set the DC offset voltage
Press Offset to set the DC offset of the current signal and the range available is
from “-2.5 V + the amplitude value currently set/2” (if the impedance is “HighZ”)
to “2.5 V + the amplitude value currently set/2” (if the impedance is “50 Ω”).
Rotate
directly to set the desired DC offset value.
