Rigol DS1000Z Series User Manual

Chapter 6 To Make Measurements RIGOL
DS1000Z User’s Guide
6-19
One-key Measurement of 24 Parameters
Press corresponding softkey under the MENU at the left of the screen to quickly
measure the 24 parameters and realize “One-key” measurement. The measurement
result will be displayed at the bottom of the screen.
The icons of time and voltage parameters in the measurement items and the
measurement results on the screen are always marked in the same color with the
channel (Measure  Source) currently used. But the delay and phase
measurement items are always marked in green. For example,
Note: if the measurement result is displayed as “*****”, it means that there is no
signal input in the current source or the measurement result is not within the valid
range (too large or too small).
