Page #127 background imageLoading...
Page #127 background image
Chapter 6 To Make Measurements RIGOL
DS1000Z Users Guide
6-13
Integrate
Calculate the integral of the specified signal source. For example, you can use
integrate to calculate the energy of a pulse or measure the area under a waveform.
Press MATH Math Operator to select intg”:
Press Display to turn on or off the integral operation function.
Press Source to select the desired channels (CH1, CH2, CH3 or CH4).
Press Offset and use to adjust the vertical offset of the operation result.
Press Scale and use to adjust the vertical scale of the operation results.
Press Scale Reset, the instrument will adjust the vertical scale to the best value
according to the current configration automatically.
Press Options to set the start point, end point or turn on or off the inverted
display of the operation results.
Press Start to set the start point of the operation results.
Press End to set the end point of the operation results.
Press Invert to turn the inverted display of the operation results on or off.
Press Auto Scale to turn on or off the auto scale function. When ONis
selected, the instrument will adjust the vertical scale to the best value according
to the current configration automatically.
HORIZONTAL POSITION and HORIZONTAL SCALE can also be
used to adjust the horizontal position and scale of the operation results.
Differentiate
Calculate the derivative of the specified signal source. For example, you can use
differentiate to calculate the instantaneous slope of a waveform.
Press MATH Math Operator to select diff”:
Press Display to turn on or off the derivative operation function.
Press Source to select the desired channels (CH1, CH2, CH3 or CH4).
Press Offset and use to adjust the vertical offset of the operation result.
Press Scale and use to adjust the vertical scale of the operation results.
Press Scale Reset, the instrument will adjust the vertical scale to the best value
according to the current configration automatically.
Press Options to set the start point, end point or turn on or off the inverted
display of the operation results.
