Rigol DS1000Z Series User Manual

RIGOL Chapter 12 Signal Source
DS1000Z User’s Guide
12-12
To Output Arbitrary Waveform
DS2000A allow users to define arbitrary waveforms and to save them to the internal
or external memory. The internal memory can store 10 arbitrary waveforms at most.
1 to 16384 points can be included in the user-defined waveforms, namely 1 pts to 16
kpts。Press Src1 Setup to enter the waveform setting interface. Press Wave to
select “Arb”, at this point, you can edit arbitrary waveforms.
1. Output
Press Output to turn the signal output on or off.
2. To set frequency
Press Frequency to set the frequency of the current signal and the range
available is from 100 mHz to 1 MHz.
Method one:
Rotate
directly to set the desired frequency value.
Method two:
Press
to input desired paramrter values and unist directly using the pop-up
numeric keyboard.
3. To set amplitude
Press Amplitude to set the amplitude of the current signal and the range
available is from 20 mVpp to 5Vpp (when the impedance is “HighZ”) or from 10
mVpp to 2.5 Vpp (when the impedance is “50 Ω”).
Method one:
Rotate
directly to set the desired implitude value.
Method two:
Press
to input desired paramrter values and unist directly using the pop-up
numeric keyboard.
4. To set the DC offset voltage
Press Offset to set the DC offset of the current signal and the range available is
from “-2.5 V + the amplitude value currently set/2” (when the impedance is
“HighZ”) to “2.5 V + the amplitude value currently set/2” (when the impedance is
“50 Ω”).
Rotate
directly to set the desired DC offset value.
