RIGOL Chapter 17 Specifications
DS1000Z User’s Guide
17-4
Idle Time 16 ns to 10 s
Number of Edges 1 to 65535
Slope Trigger
Slope Condition Positive Slope (greater than, lower than,
within specified
interval)
Negative Slope (greater than, lower than, within specified
interval)
Time Setting 8 ns to 10 s
Video Trigger
Signal Standard Support standard NTSC, PAL and SECAM broadcasting
standards
Support 480P, 576P HDTV standards
Pattern Trigger
Pattern Setting H, L, X, Rising Edge, Falling Edge
Delay Trigger
Edge Type Rising, Falling
Delay Type
> (greater than), < (lower than), <> (within the specified
interval), >< (outside the specified interval)
Delay Time 8 ns to 10 s
TimeOut Trigger
Edge Type Rising, Falling, Rising&Falling
TimeOut Value 16 ns to 10 s
Duration Trigger
Pattern Setting H, L, X
Trigger Condition
> (greater than), < (lower than), <> (within the specified
interval)
Duration Time 8 ns to 10 s
Setup/Hold Trigger
Edge Type Rising, Falling
Data Pattern H, L,X
Setup Time 8 ns to 1 s
Hold Time 8 ns to 1 s
RS232/UART Trigger
Polarity Normal, Invert
Trigger Condition Start, Error, Check Error, Data
Baud 2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps, 57600
