RIGOL Chapter 12 Signal Source
DS1000Z User’s Guide
12-18
5. Time
Press Time to set the duration time of the current point and this setting is limited
by the duration times of the previous point and the next point. The point 1 is
fixed at 0 s.
6. Insert point
Press Insert to insert a new point at the middle position of the current edited
point and the next edited point.
7. Delete point
Press Delete to delete the current point from waveform and connect the
remaining points using the currtnt interpolation method. Note that point 1 can
not be deleted.
8. Apply
Press Apply to apply the waveform currently edited.
9. Save
Press Save to enter the files store interface. Please refer to the instruction of
“
13 Store and Recall” to save the waveform files currently created in the
internal or external memory in “.arb” format. The internal memory of the
instrument can store 10 arbitrary waveforms (LocalArb.arb). If the current
position exist a file, the original file will be overwriten. You can output the
arbitrary waveforms saved in the internal or external memory and for the
specified operation, please refer to the instruction of “
To Select Waveform”.
