Rigol DS1000Z Series

RIGOL Chapter 13 Store and Recall
DS1000Z User’s Guide
13-18
Source CH1
Offset 0 dBV
Scale 500 mdBV
Center 5 MHz
Hz/Div 5 MHz
Scale 20 dBV
View Half
Unit dB/dBm
A&&B
Display OFF
Source A CH1
Source B CH1
Offset 0 U
Scale 500 mU
Threshold A 0 V
Threshold B 0 V
A||B
Display OFF
Source A CH1
Source B CH1
Offset 0 U
Scale 500 mU
Threshold A 0 V
Threshold B 0 V
A^B
Display OFF
Source A CH1
Source B CH1
Offset 0 U
Scale 500 mU
Threshold A 0 V
Threshold B 0 V
!A
Display OFF
Source A CH1
Source B CH1
