Chapter 15 Remote Control RIGOL
DS1000Z User’s Guide
4. View the device resource
The resources found will appear under the “RIGOL Online Resource” directory
and the model number and USB interface information of the instrument will also
be displayed as shown in the figure below.
5. Communication test
Right click the resource name
“DS1104Z (USB0::0x1AB1::0x04CE::DS1T0000000006::INSTR)” to select “SCPI
Panel Control” to turn on the remote command control panel (as shown in the
figure below) through which you can send commands and read data.
