Rigol DS1000Z Series User Manual

RIGOL Chapter 17 Specifications
DS1000Z User’s Guide
17-2
1000 Vpk
With RP2200 10:1 probe: CAT II 300 Vrms
Horizontal
Time Base Scale 5 ns/div to 50 s/div
Time Base
Accuracy
[1]
≤ ± 25 ppm
Time Base Drift ≤ ± 5 ppm/year
Max Delay Range Pre-trigger (negative delay): ≥1/2 screen width
Post-trigger (positive delay): 1 s to 5,000 s
Time Base Mode Y-T, X-Y, Roll, Delayed
Number of X-Ys 1 path
Waveform Capture
Rate
[2]
30,000 wfms/s (dots display)
Vertical
Bandwidth (-3dB) DS1104Z: DC to 100 MHz
DS1074Z: DC to 70 MHz
Single Bandwidth DS1104Z: DC to 100 MHz
DS1074Z: DC to 70 MHz
Vertical Resolution 8 bit
Vertical Scale 1 mV/div to 10 V/div
Offset Range 1 mV/div to 499 mV/div: ± 2 V
500 mV/div to 10 V/div: ± 100 V
Bandwidth Limit
[1]
20 MHz
Low Frequency
Response
(AC coupling,
-3dB)
≤5 Hz (on BNC)
Rise Time
[1]
DS1104Z: 3.5 ns
DS1074Z: 5 ns
DC Gain
<10 mV：±4% full scale
