Rigol DS1000Z Series User Manual

RIGOL Chapter 17 Specifications
DS1000Z User’s Guide
17-6
Math
Waveform
Operation
A+B, A-B, A×B, A/B, FFT, &&, ||, ^, !, intg, diff, sqrt, lg, ln,
exp, abs
FFT Window Rectangle, Hanning, Blackman, Hamming,Flat Top,Triangle
FFT Display Half, Full
FFT Vertical Scale dB/dBm, Vrms
Number of Buses
for Decoding
2
Decoding Type Parallel (standard), RS232/UART (option), I2C (option), SPI
(option)
Display
Display Type 7.0 inches TFT LCD display
Display Resolution 800 horizontal×RGB×480 vertical pixel
Display Color 160,000 Color (TBD)
Persistence Time Min, 100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s, 20 s,
Infinite
Display Type Dots, Vectors
I/O
Standard Ports USB HOST, USB DEVICE, LAN, Aux (TrigOut /PassFail)
Signal Sourse (DS1000Z-S)
Number of
Channels
2
Sample Rate 200 MSa/s
Vertical Resolution 14 bits
Highest Frequency 25 MHz
Standard
Waveform
Sine, Square, Pulse, Triangle, Noise, DC
