RIGOL Chapter 5 To Trigger the Oscilloscope
DS1000Z User’s Guide
Note: only one rising or falling edge can be specified in the pattern. If one edge item
is currently defined and then another edge item is defined in another channel in the
pattern, the former edge item defined will be replaced by X.
Trigger Mode:
Press Sweep to select the Trigger Mode (page 5-3) under this trigger type as auto,
normal or single. The corresponding status light of the current trigger mode turns on.
Trigger Setting:
Press Setting to set the trigger parameters (trigger holdoff and noise rejection)
under this trigger type.
Trigger Level:
Use TRIGGER LEVEL to modify the level. For details, please refer to the
description of “
Trigger Level” on page 5-9. Note that the trigger level of each
channel needs to be set respectively.
