RIGOL Chapter 5 To Trigger the Oscilloscope
5-18 MSO2000A/DS2000A User’s Guide
the default is 1.00 μs.
Vertical Window and Trigger Level:
Press Vertical to select the desired vertical window type. Rotate TRIGGER
LEVEL to adjust the trigger level. For the detailed operation, please refer to
“
Vertical Window and Trigger Level”.
Trigger Mode:
Press Sweep and select “Auto”, “Normal” or “Single”. For the details, please refer to
“
Trigger Mode”. The corresponding status light of the current trigger mode turns
on.
Trigger Setting:
Press Setting to set the trigger parameters (trigger holdoff and noise rejection)
under this trigger type.
