RIGOL Chapter 12 Display Control
12-4 MSO2000A/DS2000A User’s Guide
To Set the Waveform Intensity
Press Display  WaveIntensity or turn when the menu is hidden to adjust
the waveform brightness of the analog channel. The default is 50% and the range
available is from 0% to 100%.
To Set the Screen Grid
Press Display  Grid to set the screen grid type.
 : turn the background grid and coordinate on.

: turn the background grid off and coordinate on.

: turn the background grid and coordinate off.
To Set the Grid Brightness
Press Display  Brightness to set the brightness of the screen grid. Turn to
adjust the grid brightness. The default is 50% and the range available is from 0% to
100%.
To Set the Menu Display
Press Display  MenuDisplay to set the menu display time. The menus displayed
at both sides of the screen will hold for a specified period of time after the last
button-pressing action and then is hidden. The display time can be set to 1 s, 2 s, 5
s, 10 s, 20 s or Infinite. If “Infinite” is selected, the menus will not be hidden.
Note: When storing a file or inputting a filename, the menus will not be hidden no
matter whether the menu display time is set.
