RIGOL Chapter 11 Waveform Record
11-6 MSO2000A/DS2000A User’s Guide
Waveform Playback
Waveform playback can play back the waveforms currently recorded. After recording
the waveforms, press Utility Record Mode and use to select “Play back”.
At this point, the information as shown in the figure below is displayed at the upper
right corner of the screen, indicating the specific frame currently displayed on the
screen. During the playback, this value would change continuously.
Please refer to the following descriptions to set the playback parameters.
1. Play Mode
Press this softkey to set the playback mode to cycle or single.
: cycle playback. Play from the start frame to the end frame and then
repeat until you stop it manually.
: single playback. Play from the start frame to the end frame and
then stop.
2. Interval
Press this softkey and use
or the inner knob of the navigation knob to adjust
the time interval of playback at a relatively smaller step or turn the outer knob of
the navigation knob to adjust the time interval of playback at a relatively larger
step. The range availbale is from 100 ns to 10 s and the default is 100 ns.
3. Start Frame
Press this softkey and use
to set the start frame of playback. The default is 1
and the maximum is the maximum number of frames recorded.
4. Current Frame
Press this softkey and set the current frame using
or the navigation knob by
referring to the method mentioned above. By default, the current frame is the
same with the end frame. The setting range of current frame is related to the
start frame and end frame settings. During the setting, the screen will display
the corresponding waveform of the current frame synchronously, namely
manual playback.
If you perform the playback operation after setting this parameter, this menu will
be adjusted to the start frame value automatically and will change continuously
