Chapter 11 Waveform Record
Waveform record can record the waveforms of the analog channels (CH1 and CH2)
and the digital channels (D0-D15). In record constant on (open) mode, the
oscilloscope can record the input waveform continuously until users press
RUN/STOP. Waveform playback and analysis can provide better waveform analysis
effect.
Note:
1. The horizontal time base must be set to Y-T mode during waveform record.
2. The digital channels only support waveform record and waveform playback;
they do not support waveform analysis.
The contents of this chapter:
 Waveform Record
 Record Constant On
 Waveform Playback
 Waveform Analysis
