Chapter 5 To Trigger the Oscilloscope RIGOL
MSO2000A/DS2000A User’s Guide 5-31
Lower Limit and adjust the delay time lower limit of delay trigger using or
the navigation knob by referring to the method mentioned above; the settable
range is from 2 ns to 3.99 s.
Note: The time lower limit must be lower than the time upper limit.
Trigger Mode:
Press Sweep to open the trigger mode list and select “Auto”, “Normal” or ”Single”.
For the details, please refer to “
Trigger Mode”. The corresponding status light of
the current trigger mode turns on.
Trigger Setting:
Press Setting to set the trigger parameters (trigger holdoff and noise rejection)
under this trigger type.
Note: Noise rejection is grayed out and disabled automatically when the signal
source is set to any channel of D0-D15.
Trigger Level:
Press SourceA and use TRIGGER LEVEL to modify the trigger level of source A.
Press SourceB and use TRIGGER LEVEL to modify the trigger level of source B.
For the details, please refer to the introduction of “
Trigger Level”.
