Chapter 13 Signal Source RIGOL
MSO2000A/DS2000A User’s Guide 13-17
ON: the waveform editor connects two points using a straight line.
OFF: the waveform editor will keep a constant voltage level between the
two points and create a ladder-like waveform.
2. Zoom
Press Zoom to turn on or off the zoom function.
ON: the waveform editing window only displays the current point.
OFF: the waveform editing window displays all the initial points.
3. Current Point
Press Current to select the point to be edited. The range is from 1 to the initial
points. For the setting method, please refer to the introduction in “
Parameter
Setting Method”.
4. Voltage
Press Voltage to set the voltage of the current point. The range is from -2.5 V
to +2.5 V. For the setting method, please refer to the introduction in
“
Parameter Setting Method”.
5. Time
Press Time to set the duration of the current point. This setting is limited by the
times of the previous point and following point. The time of point 1 is fixed at 0
s. For the setting method, please refer to the introduction in “
Parameter
Setting Method”.
6. Insert
Press Insert to insert a new waveform point between the current point and the
next point.
7. Delete
Press Delete to delete the current point from the waveform and connect the
remaining points using the current interpolation mode.
Note: Point 1 cannot be deleted.
8. Done
Press Done to finish editing the current waveform.
