Rigol MSO2000A Series User Manual

RIGOL Chapter 14 Store and Recall
14-18 MSO2000A/DS2000A User’s Guide
Enable Test OFF
Source CH1
Operate OFF
Mask Range Screen
X Mask 0.24 div
Y Mask 0.48 div
Message Display OFF
Stop On Output OFF
Output Fail
AuxOutput OFF
Waveform Record
Mode OFF
Record
End Frame 4064
Operate OFF
Interval 100 ns
Total Frames 4064
Playback
Operate Stop
Play Mode Single
Interval 100 ns
Start Frame 1
Time Tag OFF
Analyze
Analysis Mode Trace
Source CH1
Trace Mode Current Frame
Current Frame 1
Template Display ON
Time Tag OFF
System Setting
Vertical Expansion Ground
Screen Saver Default
Screen Saver Time OFF
AuxOutput TrigOut
