RIGOL Chapter 1 Quick Start
1-6 MSO2000A/DS2000A User’s Guide
Connect the logic probe:
1. Connect the single-wire terminal of the logic probe to the [LOGIC D0-D15]
digital channel interface at the front panel of MSO2000A in the correct direction.
2. Connect the signal under test to the other terminal of the logic probe. MSO2000A
is provided with an RPL2316 logic probe which provides three connecting
methods with the signal under test to fulfill the requirements of different
application environment. For the details, please refer to the
RPL2316 Logic Probe
User’s Guide
.
Figure 1-6 To Connect the Logic Probe
