Chapter 1 Quick Start RIGOL
MSO2000A/DS2000A User’s Guide 1-25
Note: This function is only applicable to MSO2000A-S and DS2000A-S models
oscilloscopes.
19. Notification Area
Display the system time, sound icon, USB storage device icon and PictBridge
printer icon.
 System Time
Displayed in “hh:mm (hour:minute)” format. When printing or storing
the waveform, the output file will contain this time message. Press
Utility  System  System Time  System Time to set through
the following format: yyyy-mm-dd hh:mm:ss (year-month-date
hour:minute:second)
 Sound Icon
When the sound is enabled, will be displayed. Press Utility  Sound to
enable or disable the sound.
 USB Storage Device Icon
When a USB storage device is detected,
will be displayed.
 PictBridge Printer Icon
When a PictBridge printer is correctly connected to the oscilloscope,
will
be displayed in this area.
20. Operation MENU
Press any softkey to activate the corresponding menu. The following
symbols might be displayed in the menu.
Denote that
at the front panel can be rotated to select the
parameter items. The backlight of
turns on when the parameter
selection is valid.
Denote that
can be rotated to modify the parameter values. The
backlight of
turns on when the parameter input is valid.
Denote that
can be rotated to modify the parameter values and
press
to input the desired paramrter values directly using the
pop-up numeric keyboard. The backlight of
turns on when the
parameter input is valid.
Denote that you can rotate the “Navigation Knob” to quickly
adjust/locate parameters.
Denote that you can rotate
to adjust the parameter and then
press down
to select the parameter. The backlight of is
