2.4.20. LDW: Calibrate Zero Dead Weight
This command is used to calibrate the zero dead weight. It is possible to calibrate
the zero dead weight by either having no load on the scale base or by entering the
calculated signal directly.
General Details
No. of Parameters Save Changes Changes Used Increment Trade Counter
0 (2 if using direct
zero calibration)
With TDD1 Immediately Yes
Parameter Details
Parameter Description Range Default Required
1 Calibration type 0
1
Normal calibration
Direct calibration
0 No
2 Signal Value of zero
(in mV/V x 10000)
Signed number (decimal)
with no decimal points
No
The LDW?1; query returns the zero value in mV/V.
• Calibration with Weight
Due to increased averaging, this calibration process takes some time to complete.
As a result it is necessary to monitor the calibration process to determine when it is
finished. To do this, issue a LDW?; query. Following is a list of possible responses.
Calibration Status
Status value Description
0 Calibration finished successfully
1 Calibration in process (busy)
101 Error Zero to high (>2mV/V) Calibration aborted
102 Error Zero to low (<–2mV/V) Calibration aborted
Example
Command Response Details
S01; Select Instrument 1
LDW; 0 CRLF Start Zero Calibration
LDW?; 1 CRLF Query Status of Zero Calibration Process
LDW?; 1 CRLF Still Busy
LDW?; 0 CRLF Zero Calibration Finished (Raw Zero Value)
TDD1; 0 CRLF Save Setting
• Direct Calibration
Example
Command Response Details
S01; Select Instrument 1
LDW1,5076; 0 CRLF Set Zero Dead Load to 0.5076mV/V
LDW?1; ^^^^5076 CRLF Zero Dead Load is 0.5076mV/V
TDD1; 0 CRLF Save Setting
