2.4.13. ESR: Query Error Status
This is used to query the error status of the instrument.
General Details
No. of Parameters Save Changes Changes Used Increment Trade Counter
1 - - No
Parameter Details
Parameter Description Range Default Required
1 Select Type of
Status Information
0
1
Normal
Latched
0 No
The 5200 contains both current and latched error status flags. The latched errors
are only cleared by resetting the instrument (ie. using the RES command or
powering off). The response string is four hexadecimal characters representing the
16 error bits.
Error Codes
Error Description Resolution
0001 Power supply voltage too low. Check supply
0002 Power supply voltage too high. Check scale / cables
0004 Load cell excitation voltage too low. Check scale / supply
0008 Load cell excitation voltage too high. Check scale / supply
0010 Temperature outside allowable limits. Check location
0020 Scale build is incorrect. The number of
graduations has been set less than 100 or
greater than 100000.
Fix up scale build
0040 Positive sense line not connected. Check connection
0080 Negative sense line not connected. Check connection
00C0 Neither sense line connected. Check connection
0100 Digital setup information lost. Re-enter setup
0200 Calibration information lost. Re-calibrate
0300 All setup information lost Enter setup and calibrate
0400 Factory information lost. Service
0800 EEPROM memory storage chip failed. Service
2000 Clock calendar chip failed. Service
4000 Battery backed RAM lost data. Re-enter setup
8000 EPROM memory storage chip failed. Service
