Rinstrum - 5200 Communications Manual Rev 1.2
0025-605-120 Page 33
2.4.22. LIV: Set Limit Value
This is used to set parameters for the setpoints.
General Details
No. of Parameters Save Changes Changes Used Increment Trade Counter
10 With TDD1 Immediately No
Parameter Details
Parameter Description Range Default Required
1 Setpoint
Number
0 to 3 - Yes
2 Hysteresis 0 to 999999 0 No
3 Type 0
1
2
3
4
5
6
7
None
Active
Checkweigh Output
Error
Motion
Zero
Net
Hold
0 No
4 Source 0
1
2
Gross Reading
Net Reading
Displayed Reading
(gross/net)
1 No
5 Direction 0
1
Over
Under
0 No
6 Logic 0
1
2
3
High
Low
Pulse
Repeat
0 No
7 Alarm 0
1
2
3
4
None
Single Beeps
Double Beeps
Continuous Beep
Flash Display
0 No
8 Pulse: Delay 0 to 30000 (x100 seconds) 0 No
9 Pulse: ON
Time
0 to 30000 (x100 seconds) 0 No
10 Pulse: OFF
Time
0 to 30000 (x100 seconds) 0 No
Note: Setpoint targets are set for each product using the PRD command.
Example
Command Response Details
S01; Select Instrument 1
LIV?0; 0,0,0,1,0,0,0,0,0,0 CRLF Query Setpoint 1 Parameters
LIV0,5,1,,1,1; 0 CRLF Change to:
Hysteresis = 5
Type = Active
Direction = Under
Logic = Low
TDD1; 0 CRLF Save Setting
