6.3 Tab "Personality"
User mode - The Robin Forte allows you to recall two user settings. After switching the xture on for the rst
time, the User A settings is active. Now all changes made in the “Personality” menu , ”Addressing” menu and the
“Music Trigger“ and “ Preset Playback“ items from the “Stand-alone” menu are saved to the User A settings. If
you now select the User B settings, from this moment the changes made in these menus will be saved to the
User B settings. After switching the xture o󰀨 and on, the User B setting is active. In this way you may use the
two xture operating behaviours.
User A Settings - the function recalls the user A settings.
User B Settings - the function recalls the user B settings.
DMX Preset channels - Use the menu to display overview of control channels.
DMX Input- Use the menu to select mode of DMX signal receiving.
Wired - DMX signal is received by means of the standard DMX cable.
Wireless - DMX signal is received by means of the inbuilt wireless module.
Wireless In/XLR Out- the xture receives wireless DMX and sends the signal to its wired DMX output.
The xture behaves as " Wireless/Wired" adapter.
The options "Wired" and "Wireless" are also stated in DMX chart (channel Power/Special functions).
Note. If the wireless module is not installed in the xture, the following message will appear:
DMX Input Set to Wired
Wireless Module Missing
If the xture is not connected to mains, the message "Not Available In O󰀪ine Mode" will appear after entering
the menu DMX Input. To enter this menu, the xture has to be connected to mains.
Pan/Tilt Settings - Use the menu set behaviour of both pan and tilt movements.
Pan Reverse - The item allows to invert pan movement.
Tilt Reverse - The item allows to invert tilt movement.
Pan/Tilt Feedback - The item allows to return the mowing head to the required pan/tilt position after
changing the position by an external force if this option is set on.
Note. Be careful, the Pan/Tilt Feedback should be permanent On, the option O󰀨 is not suitable for standard
operation and the head of the xture can be damaged!
Pan/Tilt mode - Use this menu to set the mode of the pan/tilt movement
Time mode – The pan and tilt will move with di󰀨erent speeds and they will come at
the same time to the end point of their tracks (pan and tilt use their optimal speeds).
Time of the pan/tilt movement (25.5 sec. max.) is set by the channel "Pan/Tilt speed, Pan/Tilt
time".
Speed Mode - Both Pan and tilt will move with the same speed as adjusted at the channel
"Pan/Tilt speed, Pan/Tilt time".
Pan/Tilt Reset - This menu item allows you to choose a way of pan/tilt reset after switching the xture on
With P/T - With pan and tilt - the item will reset both pan and tilt simultaneously after switching the xture on.
Without P/T - Without pan and tilt reset after switching the xture on. The pan and tilt reset can be run by
the menu Manual Control (Manual Control --> Reset Functions) or by DMX commands.
Tilt then Pan - the item will reset pan and tilt sequentially, rst tilt, then set tilt to DMX 128 and reset pan.
Pan then Tilt - the item will reset pan and tilt sequentially, rst pan, then set pan to DMX 128 and reset tilt.
Note: DMX triggered pan/tilt related reset commands on the channel Power/Special functions always behave
in this way:
"Total xture reset (including pan/tilt)" - resets all functions including pan and tilt. Pan and tilt always are reset,
either simultaneously or sequentially.
"Total xture reset (without pan/tilt)" - resets all functions except pan and tilt. When set to simultaneous reset
(the standard reset With P/T), the head will position itself briey into dened position for reset of the optical
system.
"Pan and Tilt reset" - pan and tilt always are reset, either simultaneously or sequentially (depends on setting in
the display menu Personality --> Pan/Tilt Reset).
"Pan reset" - resets pan, tilt is static in the position of a tilt DMX value received when pan reset was received.
"Tilt reset" - resets tilt, pan is static in the position of a pan DMX value received when tilt reset was received.
Pan/Tilt EMS - Built-in electronic motion stabilizer ensures precise position of the xture´s head during its
movement and also reducing its swinging when the truss shakes.
