28
Fr. Shutter 2 Swiv.- a Fram. lamella 2 ne swivelling
Fr. Shutter 3 Move - a Fram. lamella 3 ne moving
Fr. Shutter 3 Swiv. - a Fram. lamella 3 ne swivelling
Fr. Shutter 4 Move - a Fram. lamella 4 ne moving
Fr. Shutter 4 Swiv. - a Fram. lamella 4 ne swivelling
Calibration of the eects via the control board
1. Disconnect DMX controller from the xture and enter the "Calibrate E󰀨ects" menu.
2. Use the [up arrow] and [down arrow] to nd "Pan" and touch it to enter the ne e󰀨ect adjustment screen.
3. Set desired value and save it by touching the [conrm].
4. Repeat steps 2 and 3 for next item.
5. After calibrating all e󰀨ects, touch the [conrm] to save all adjusted values and reset the xture.
Calibration of the eects via the DMX controller
1. Connect DMX controller to the xture and enter the "Calibrate E󰀨ects" menu.
Calibration protocol:
E󰀨ect
Pan channel 45
Tilt channel 46
Rot. Gobo Wheel channel 47
R. Gobo Index 1 channel 48
R. Gobo Index 2 channel 49
R. Gobo Index 3 channel 50
R. Gobo Index 4 channel 51
R. Gobo Index 5 channel 52
R. Gobo Index 6 channel 53
R. Gobo Index 7 channel 54
R. Gobo Index 8 channel 55
Static gobo channel 56
Colour wheel channel 57
Cyan channel 58
Magenta channel 59
Yellow channel 60
Prism 1 channel 62
Prism 2 channel 63
Zoom channel 64
Focus channel 65
Iris channel 66
Frost 1 channel 67
Frost 2 channel 68
Fr. Shutters rot. channel 69
Fr. Shutter 1 Move channel 70
Fr. Shutter 1 swiveling. channel 71
Fr. Shutter 2 Move channel 72
Fr. Shutter 2 swiveling channel 73
Fr. Shutter 3 Move channel 74
Fr. Shutter 3 swiveling channel 75
Fr. Shutter 4 Move channel 76
Fr. Shutter 4 swiveling channel 77
Calibrate Fr. Hysteresis
Framing Lamella 1 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 2 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 3 - a framing lamella 1 reverse movement (value range: 0-8)
Framing Lamella 4 - a framing lamella 1 reverse movement (value range: 0-8)
The value set for every framing lamella gives a value at which the lamella reacts to its reverse
movement promptly (without movement hysteresis).
Calibrate Pan/Tilt EMS - This menu item allows calibration of the pan/tilt electronic motion stabilizer.
Important: during this calibration any external force must not inuence the xture and the surface at which
the xture stands (or truss if the xture hangs) has to be without movement, shake, strokes etc.
Load Default Calibrations - The item loads default (factory) calibration values.
