Robe Painte - Page 29

29
Rotating Gobos Change - This menu makes changing of rotating gobos in the xture easier.
Gobo Carousel - The menu allows movement of rotating gobos on the gobo carousel to positions suitable
for their changing.
G1-Mg - a movement of the gobo 1 (gobo holder with magnet) to the changing position.
G2 - a movement of the gobo 2 to the changing position.
:
G8 - a movement of the gobo 8 to the changing position.
Gobo O󰀨set -a gobo o󰀨set setting. The function allows ne swiveling of the gobo holder. The set value
is valid for all gobos on the gobo carousel.
LEDs Measure - This menu item runs a procedure which measures a light intensity of the LEDs module installed
in the xture. This procedure takes about 1 minute (message " LEDs Module Measurement" is displayed on
the screen"). During the procedure the xture does not receive DMX signal, pan/tilt go to 128 DMX, a shutter
is open and a dimmer is set at max. light intensity (255 DMX). All e󰀨ects are taken out from the light beam.
The measured light intensity is recorded in the item Intensity in the menu LED Module Info:
Tab Information --> LED Module Info--> Actual Module Info --> Intensity
Tab Information --> LED Module Info-->Intensity History --> Intensity
The light intensity in the menu item Intensity is displayed in percentages in relation to the initial intensity of the
new LEDs module (initial intensity=100%).
The LEDs Measure procedure should be run after every change of the LED light source.
Note: The xture has to be connected to mains in order to run LEDs Measure procedure.
Update software - The menu item allows you to update software in the xture.
The following items are required in order to update software:
- PC running Windows or Linux or macOS
- DSU le
- Flash cable RS232/DMX, P/N13050624 (if you want to use a serial port of PC)
- Robe Universal Interface or Robe Universal interface WTX (if you want to use an USB port of PC)
After the software updating the xture will be set to default values.
The following items are required in order to update software:
- PC running Windows or Linux or macOS
- DSU le
- Flash cable RS232/DMX, P/N13050624 (if you want to use a serial port of PC)
- Robe Universal Interface or Robe Universal interface WTX (if you want to use an USB port of PC)
After the software updating the xture will be set to default values.
To update software in the xture:
1. DSU le is available from Robe web site at WWW.robe.cz.
File with extension zip is intended for Windows (used and tested from XP to W10 on 32/64bit systems).
File with extension tbz is intended for Linux (used and tested on Debian and Ubuntu 32/64bit).
File with extension dmg is intended for macOS (used and tested on OSX up to Sierra) XQuartz required,
install it from https://www.xquartz.org/
Save the download le to a folder on your computer.
In case that you use windows, extract les in the zip le (e.g. DSU_RobinPainte_21091633.zip)
2. Disconnect the xture from DMX controller.
3. If you use the ash cable RS232/DMX, connect a serial port of your computer with DMX input of the xture
by means of the cable.
If you use the Robe Universal Interface, connect a USB port of your computer with the Robe Universal Interface
by means of the USB cable and DMX input of the xture with the DMX output of the Robe Universal Interface
via a DMX cable.
4. Switch the xture to the update mode (Special -> "SW Upd "-> On).
Note: If you do not want to continue in the software update, you have to switch o󰀨 and on the xture
to escape from the updating mode.
We recommend to cancel all running programs on your computer before starting the software update.
5. Double-click the software uploader le (e.g. DSU_RobinPainte_21091633.exe) in
the extracted les. The Software Uploader program will start to run.
